Model SRU-1615-HT

Medium Wave Systems model SRU-1615-HT

BACK

THE CONTROL YOU WANT FOR A FLAWLESS FINISH.

Medium Wave Systems feature quartz elements, which offer uniform and forgiving heating capabilities. Infratech medium wave systems are available in a range of wattages and configurations, to provide heat distribution and faster cure speeds across coverage areas of varying sizes.

Control

Practical, precise electric infrared technology transfers heat directly to your product, without heating the surrounding air, for faster heat transfer and greater control for spot heating.

Adhesion

Infratech electric infrared products are ideal for a wide range of automotive refinishing and wood-working applications. They can safely be used on plastic, aluminum, steel and fiberglass components.

Coverage

Medium Wave systems feature quartz elements that provide accelerated drying and curing times and even heat distribution, for a flawless finish in record time.

60 MINUTE TIMER FOR ENERGY SAVINGS

SPRING LOADED PIN FOR QUICK ADJUSTMENTS

LARGE CASTERS FOR ADDED MOBILITY

PRODUCT DETAILS
  • Part. No. 16-1000
  • High intensity medium wave fixture offers increased power (2,000 watts) and improved cure times over a 3' x 4' coverage area
  • 60-minute timer conserves energy and automatically shuts unit down when curing is complete
  • Heavy-duty stand adjusts to over 6' high for curing hoods and roof lines with new larger casters for enhanced mobility
  • Parabolic reflector creates uniform heat distribution
  • Operates vertically or horizontally, in order to cure hard-to-reach areas, and offers increased flexibility for small repairs
  • Also available in 240 volts (Part No. 16-1005)
    • PRODUCT SHEET
    INSTRUCTIONS
    DOWNLOAD CATALOG
    DOWNLOAD SPANISH CATALOG
    SPECIFICATIONS
  • SPECIFICATIONS
  • 2,000 watts
  • 120 volts
  • 17 amps
  • 36" head
  • 26 lbs.
  • REPLACEMENT ELEMENT PART NO.
  • E-2012SR (#10-3080)

    • Please Note: Part Numbers listed above represent element replacements for standard catalog units. Fixtures with different voltages may require a different part number. Please consult with your Infratech representative when making your order.

    COVERAGE AREA
    coverage_area
    Slide to View
